RECORD MODE
Set up record type.
NORMAL+EVENT is focused record mode.
NORMAL/EVENT RECORD FPS
Set up how many frames to record.
NORMAL/EVENT RECORD QUALITY
Set up record quality.
SCHEDULE
Set each week’s schedule.
Schedule Record setup
Type A
( 4CH )
Type B
( 9CH )
Type C
( 16CH )
D1 120 FPS 120 FPS 120 FPS
Half-D1 120 FPS 240 FPS 240 FPS
CIF 120 FPS 270 FPS 480 FPS
Recording Frame rate in different device type as below table (NTSC Mode)
*The aspect ratio of local AVI backup is
incorrect when recorded format is half D1.
*It doesn't support de-interlace for D1 format
except local AVI backup
