5
2) LOOP OUT Connection
3) Monitor Connection
It connects audio source (mic) to audio
input of RCA and connects speaker to
audio output.
It supports 10/100 BaseT, connects
Cat5 cable with RJ-45
System rear connection detail
1) Video Source Connection
It connects video sources (camera image) to BNC connector via cable.
BNC connector of LOOP OUT can be used other device’s input.
CVBS OUT/SPOT : It connects normal CCTV CRT monitor.
S-VHS : It connects monitor that supports S-VHS(S-VIDEO)
VGA : It connects PC monitor or LCD monitor (not supporting DVI)
4) Audio Connection 5) Network Connection
1. It may cause low quality of picture when connecting cable
from any device to LOOP OUT BNC.
2. Type A doesn’t support Loop out connection.
1.Type A doesn’t support S-VHS output.
2.Type A only offers 1 Spot output .
