6) RS232 port Connection.
RS232 port is connected to PC and other devices for specific function and After Sales purpose.
It consists of 1 USB (Front), 1 USB (Rear), its supported devices are such as USB mouse, USB
external HDD and USB memory stick
* Alarm output 1~4CH
It can be on/off for buzzer, headlamp etc.
Alarm input mode consists of NORMAL OPEN and NORMAL CLOSE.
Ref : The spec. Max24V/2A
7) USB port Connection
8) ALARM IN(SENSOR) Connection
It consists of ALARM IN(SENSOR) and G(GND).
Ref : The spec. is Max 6V/50mA
9) ALARM OUT Connection
front rear
Type A support 4 Alarm in .
Type B support 8 Alarm in .
Type C support 16 Alarm in .
Type A support 1 Alarm out .
Type B support 4 Alarm out .
Type C support 4 Alarm out .
