Hi-view LS1 User Manual

6
5. Charging the Battery
 1~2 hours if using Charger to charge the battery
 About 6~7 hours if using USB cable
 Before first use battery , charge the battery 8 hours by charger
6.SPECIFICATION
LS1
Sensor
5 Megapixel CMOS
Lens
F1.4/7G :120° (Optional F2.0/6G: 150°)
Resolution
720P:1280X720 WVGA:848X480
FPS per second
720P Mode: 30fps
Compression
H.264
Format
AVI
Shockproof
2.5Meter
WaterProof
IP68 ( underwater 30 Meter)
Time/Date
Yes
Circular record
5 minutes
Audio
Excellent microphone sensitivity
Storage
Support Micro SD upto 32GB (Class 6 or above )
Operating
-40°C~80°C
Size
Ø34mm X110mm
Weight
109g (not incl. battery 21g)
LS1 Power
Mini USB DC5V
Battery
3.6v 750mA Li-ion
Charger
AC100-240V

Hi-view LS1 Specifications

General

Brand	Hi-view
Model	LS1
Category	Digital Camera
Language	English
