HID ACW2-XN Quick Install Guide

Power Supply (A-X1)
AC Mains Input 100-230 VAC (50/60Hz), 1.3A
DC Output 12V, 5A
Controller (AC)
Power Input 12V DC (Factory Pre-wired)
Network 10/100 Base T, half or full duplex
Wiegand Module (AW2)
Relay Rating [10A, 28VDC] [5A, 220VAC] [12A, 120VAC]
Recommended
Cable Specifications
Input & Wiegand: >=22AWG, Max 150m
Relay: >=18AWG, Max 150M
Specifications
HID Access Manager
Initial Connection
Using a Router with DNS active
 Type: “//HIDaccess/” as the URL of any HTML5 compliant
web browser such as Chrome
Using a Switch or Direct Connection:
 Type: “//192.168.100.1/” as the URL of any HTML5 compliant
web browser such as Chrome
 The client PC must be in the same subnet (192.168.100.#)
Default Password: “12345”
Required Settings
1. Set the date and time
2. Update the master password
3. Add/Configure doors and readers
4. Add/Manage people
Note:
 It is best practice to use an additional fused power supply for the locks
