6
ENGLISH
NOTE:
Pleasepayattentiontothecorrectpolarity(+or-)
for all terminals and connections.
VX6.2E, VX5.2E
WIRING DIAGRAM
(must be made for right and left side of the vehicle)
Tweeter
Midbass Woofer
Crossover
ToAmplier
+ red marked
+ red marked
