High-End Technology F-20 - Page 9

9"
www.EJF.com"
PICTURE ON LEFT: Servo Control Horn Cut out on the Vertical stab
PICTURE ON RIGHT: Sand the fuselage and the inside of the Vertical Fin, the example above is the F-16 shown for
illustration. Test fit everything and then satisfied, Glue the vertical fin the body.
.
PICTURE ON LEFT: Connect your servo to the Rudder now that your vertical fin is glued to the body.
