4
Board Layout
RocketRAID 600L PCB board Layout
Connector and Jumper description
Connector /
Jumper
RocketRAID
640L
RocketRAID 642L
RocketRAID
644L
RocketRAID
644LS
A1 Active LED PIN N/A
F1 Fail LED PIN N/A
