5
J1 I2C Connector N/A
BEEP1 Alarm Buzzer
PORT1 to
PORT4
SATA
Connector
SATA and eSATA
Connector
eSATA
Connector
Mini-SAS
Connector
Active/FAIL LED PIN connector:
This connector is one-pin connection from HBA to LED on chassis.
For detail LED connection requirement and display information,
please refer to:
http://www.highpoint-tech.com/PDF/LED_connection.pdf
Hardware Installation
Installing the RocketRAID 600L Series HBA
Note: Make sure the system is powered-off before installing the
RocketRAID 600L Series HBA.
1. Open the system chassis and locate an unused PCI-E (2.0/1.0) (x4,
x8, x16) slot or (3.0) (x16) slot.
2. Remove the PCI slot cover.
3. Gently insert the RocketRAID 600L HBA into the PCI-E slot, and
secure the bracket to the system chassis.
4. After installing the adapter, attach the hard disks or disk enclosure
to the RocketRAID 600L HBA using the SATA cables.
5. Close and secure the system chassis.
Using the RocketRAID 600L Series HBA
RocketRAID 600L HBA BIOS
After installing the RocketRAID 600L Series HBA, and powering on the
system, the adapter BIOS should post.
The BIOS will scan for devices and display information about each disk.
