Hikari H9199 User Manual

1 103.08-27 柱塞 PLUNGER
2 103.08-29-2 柱塞弹簧 SPRING COMPRESSION
3 12-065150 O型圈 O RING
4 113.08-29-01 泵盖螺钉 CAP SCREW
5 123.08-17 密封垫片 GASKET
6 123.08-15 油嘴 OIL FEEDING PIPE
7 123.08-16 通气螺钉 SCREW
8 12-036140 O型圈 O RING
9 123.07-05 油量调节螺钉 ADJUSTING SCREW
10 103.08-36-1-4A 油管 OIL TUBE
11 123.08-10 O型圈 O RING
12 01-404000423-1
螺钉
M4×4
SCREW M4×4
13 05-043101200-1 平垫圈4.3×12×1.0 WASHER PLAIN 4.3×12×1.0
14 123.08-11 油棉 BOTTOM COVER FELT
15 123.08-05 齿轮箱盖 BED BOTTOM COVER
16 12-046220 O型圈 O RING
17 01-608001021-4 螺钉 M5×14 SCREW M5×14
18 12-190265 O型圈 O RING
19 101.09-01 油窗 OIL SIGHT WINDOW
20 22-13505015 橡胶塞 RUBBER CAP
21 12-078180 O型圈 O RING
22 125.08-01 通气塞 VENT PLUG
23 01-405001423-1
螺钉
M5×14
SCREW M5×14
24 123.08-04-01 油盒 OIL TANK
25 18-405001222-4
螺
钉M5×12
SCREW M5×12
26 123.08-02-05 磁铁 MAGNET
27 123.08-02-06 传感器转轴 SHAFT
28 123.08-02-03 螺纹连接杆 THREADED ROD
29 123.08-02-04 浮子连接杆 FLOAT CONNECTING ROD
30 123.08-02-07 传感器转轴 AXIS
31 123.08-02-02 浮子 FLOAT
32 123.08-02-11 霍尔安装套 INSTALLATION SETS
33 30008594 插件霍尔 PLUG-HALL
34 X-123-02-0A0 油量传感器信号线 WIRE
35 CB14-01-0A0 油量标定PCB组件 AN OILCONTROL OF PCB ASM.
36 123.08-04-04 罩板 COVERE
37 20-4290832-3 螺钉 SCREW
38 X-125-01-0A0 油量传感器长线 WIRE
1
1
1
H9199N-7C-5
1
1
1
1
1
1
1
1
1
1
4
数量QTY.
2
序 号
PEF.NO.
图 号
PART NO.
名 称
7.润滑系统 / Lubrication
NAME OF PARTS
3
1
4
2
1
1
4
1
1
1
1
1
1
1
7
4
2
1
1
1
1
1
1
- 77 -
