Hikari H9199 User Manual

1 103.09-14-03 面板线钩 FACE PLATE THREAD GUIDE
2 01-435000623-1 螺钉 M3.5×6 SCREW M3.5×6
3 01-805000514-1 内六角凹端紧定螺钉 SCREW
4 101.03-07 针杆下套线钩 THREAD GUIDE
5 113.12-00 起针夹线器 THREAD TENSION ASM.
6 113.09-03 夹线器组件 THREAD TENSION BRACKET ASM.
6-1 113.09-03-01 挑线簧调节座 THREAD TENSION BRACKET
6-2 02-909400421-1 螺钉 SET SCREW
6-3 101.01-27-06 夹线螺钉 TENSION STUD
6-4 101.01-27-07 挑线簧 THREAD TAKE-UP SPRING
6-5 101.01-27-05 夹线板 TENSION DISC
6-6 101.01-27-04 松线板 TENSION DISC PRESSER
6-7 101.01-27-03 夹线弹簧 TENSION SPRING
6-8 101.01-27-02 夹线制动板 WASHER
6-9 101.01-27-01 压线螺母 TENSION NUT
7 108.10-18 线导向勾 THREAD GUIDE P-BAR BRACKET
8 01-804000614-1 内六角螺钉 M4×6 SCREW M4×8
9 19-405000823-2
螺
钉M5×8
SCREW,M5×8
10 103.09-10 机壳线导向 ARM THREAD GUIDE
11 02-815281211-1
螺钉SM15／64
"×28×1
2
SCREW SM15／64"×28×12
12 110.01-21G 调线夹线器组件 PRE-TENSION ASM.
12-1 110.01-23G 夹线过线板 THREAD TENSION GUIDE
12-2 110.01-21-01G 调线夹线螺钉 THREAD TENSION POST
12-3 101.01-21-03 小夹线板 THREAD TENSION DISK
12-4 101.01-21-04 小夹线簧 THREAD TENSION SPRING
12-5 101.01-21-05 小夹线螺母 THREAD TENSION NUT
13 125.06-01 松线电磁铁组件 THREAD RELAX SOLENOID ASM.
14 103.09-12 挑线杆防护罩 THREAD TAKE-UP LEVER COVER
15 01-405000623-1 螺钉 SCREW M5×6
16 110.01-07 面线过线板 THREAD PLATE
17 102.09-32A 绕线器组件 BOBBIN WINDER UNIT
18 02-312320722-3 十字槽半圆头螺钉 SCREW
19 102.09-34 切刀 KNIFE
20 02-409400523-1 螺钉SM9／64"×40×5 SCREW SM9／64"×40×5
21 102-09-36 夹线器组件 THREAD TENSION ASM.
21-1 04-611400300-1 螺母 NUT
21-2 102.09-36-03 夹线簧 SPRING
21-3 102.09-36-04 夹线板 THREAD TENSION DISK
21-4 102.09-36-02-01 调线过线板 THREAD TENSION GUIDE
21-5 102.09-36-02-02 夹线螺钉 SCREW
21-6 102.09-36-01 夹线螺母 THREAD TENSION NUT
1
1
2
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
H9199N-7C-5
1
8.穿线装置&卷线装置 / Bobbin winder mechanism & Threading mechanism
序 号
PEF.NO.
图 号
PART NO.
名 称 NAME OF PARTS
数量QTY.
1
1
1
3
1
1
1
1
1
1
1
1
2
1
1
1
2
1
1
3
