11
Battery
Lights ;
The battery remaining power is over 75%.
Lights ;
The battery remaining power is 50%–75%.
Lights ;
The battery remaining power is 25%–50%.
Lights ;
The battery remaining power is less than 25%.
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or malfunction.
The problem may be the battery so please
contact your dealer.
SPECIFICATIONS
1. Cordless Brad Nailer
Model NT1850DF
Motor DC Brushless
Applicable Nail 18 Ga
Applicable Nail Length 16 mm to 50 mm
Nail Loading capacity [nails] 100 (1 strip)
Firing mode Single sequential / Contact
(Selectable)
Cycle rate [nails/second] 2 (Intermittent)
Battery Model BSL1820M
Type Li-ion battery
Voltage DC 18V
Weight* 2.4–3.0 kg
Dimension
Height × Length × Width 286 mm × 267 mm × 92 mm
* Weight: According to EPTA-Procedure 01/2014
2. Battery Charger
Model UC18YFSL
Charging voltage DC 14.4–18 V
Weight 0.5 kg
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
NAIL SELECTION
Only nails shown in the Table below can be driven with this Nailer.
Dimensions of nails
18 Gauge brad nails
(straight)
Min.
Max.
1.9 mm
16 mm
1.25 mm1 mm
1.1 mm
50 mm
