6. Attach one end of the ventilation tube (16) to the bacteria filter (23) and the other end
to the nebulization chamber lid.
7. Connect the adjustable arm set (14) to the main stand rod. Connect the aerosol tube
(15) to the arm set’s black plastic clips. The support arm should tighten and secured
ensuring that the position of the aerosol tube is pointing upwards and straight, allowing
any collected aerosol to flow back into the chamber.
8. To start the aerosol therapy, place the required dose of medication into the
disposable medication cup (38), and connect to the chamber (11) and its lid (36). Locate
and lock the nebulization chamber in its place to the unit (22) by turning to the right.
5. Device Image and Components
1. Wheel
3. Middle base connector
4. Locking nuts
5. Bracket clamp
6. Stand rod
8. Bottle holder
11. Nebuliser chamber
14. Adjustable arm set
15. Aerosol tube
16. Ventilation tube
19. Heater
21. Oxygen adapter
22. Holding device
23. Bacterial filter (round)
26. Five feet
36. Nebuliser chamber lid
38. Medical cup
