Code: DS-2CD2023G0-I(2.8MM)

IP CAMERA DS-2CD2023G0-I(2.8MM) - 1080p Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60

2021-06-07 DS-2CD2023G0-I(2.8MM) 3/6

ONVIF: 16.12

Mobile phones support:

Port no.: 8000 or access by a cloud (P2P)

• Android: Free application iVMS-4500 or Hik-Connect

• iOS (iPhone): Free application iVMS-4500 or Hik-Connect

Default admin user / password:

admin / -

The administrator password should be set at the first start

Default IP address: 192.168.1.64

Web browser access ports: 80

PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application

Mobile client access ports: 8000

Port ONVIF: 80

RTSP URL:

• Main stream

rtsp://192.168.1.64:554/Streaming/Channels/101/ - RTSP - without authorization

rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ - with

authorization

• Sub stream

rtsp://192.168.1.64:554/Streaming/Channels/102/ - RTSP - without authorization

rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ - with

authorization

RS-485 interface:

Main features:

• WDR - 120 dB - Wide Dynamic Range

• 3D-DNR - Digital Noise Reduction

• ROI - improve the quality of selected parts of image

• BLC - configurable Back Light Compensation

• HLC - High Light Compensation (spot)

• AGC - Automatic Gain Control

• ICR - Movable InfraRed filter

• Day/Night mode (color/b&w/auto)

• Configurable Privacy Zones

• Motion Detection

• RESET button

• Intelligent Image Analysis : intrusion, crossing the line (tripwire), face detection

• Sharpness - sharper image outlines

Power supply:

• PoE (802.3af),

• 12 V DC / 500 mA

Power consumption:

≤ 6 W @ PoE

≤ 6 W @ 12 V DC

Housing: Compact, Aluminum

Color: White

Operation temp: -30 °C ... 60 °C

"Index of Protection": IP67

Supported languages:

Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek,

Spanish, Dutch, Lithuanian, Latvian, German, Norwegian, Portuguese, Russian,

Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Vietnamese,

Italian

Weight: 0.4 kg

Dimensions: Ø 70 x 155 mm

Questions and Answers:

Need help?

Do you have a question about the HIKVISION DS-2CD2023G0-I and is the answer not in the manual?

HIKVISION DS-2CD2023G0-I Specifications

General

Type	IP security camera
Languages support	Multi
Number of languages	32
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Total megapixels	2 MP
Gain control type	Auto
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Analog signal format system	NTSC, PAL
Supported graphics resolutions	352 x 240, 352 x 288, 640 x 360, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Fixed focal length	2.8 mm
Maximum aperture number	2
Minimum aperture number	1.2
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Intelligent Video Surveillance (IVS) system features	Face detection
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Lens mount interface	M12
Behavior analysis	Intrusion detection, Line crossing detection
Number of users	32 user(s)
User access level	Administrator, Operator, User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7.5 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
