HIKVISION DS-2CD2386G2-I User Manual

User Manual
Code: DS-2CD2386G2-I(2.8MM)
IP CAMERA DS-2CD2386G2-I(2.8MM) ACUSENSE - 8.3 Mpx Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-06-07 DS-2CD2386G2-I(2.8MM) 3/6
Network interface: 10/100 Base-T (RJ-45)
Network protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP,
UPnP, SMTP, SNMP, IGMP, IEEE 802.1x, QoS, IPv6, UDP, Bonjour, SSL, TLS
WEB Server: Built-in
Max. number of on-line users: 6
ONVIF: 18.12
Main features:
• WDR - 120 dB - Wide Dynamic Range
• 3D-DNR - Digital Noise Reduction
• ROI - improve the quality of selected parts of image
• BLC/HLC - Back Light / High Light Compensation
• EXIR - high-efficiency infrared LEDs technology, which evenly covers the whole
plan of both central vantage points of the scene as well as the corners
• Anti-Flicker - The technology eliminates the tiring eyes flickering image effect
• ICR - Movable InfraRed filter
• Possibility to change the resolution, quality and bit rate
• Configurable Privacy Zones
• Motion Detection
• Mirror - Mirror image
• Filtering of false alarms based on the recognition of persons and vehicles
• Intelligent Image Analysis : crossing the line (tripwire), intrusion, detection of entry
into the area / exit from the area, scene changing, face detection, advanced face
capture features
Mobile phones support:
Port no.: 8000 or access by a cloud (P2P)
• Android: Free application iVMS-4500 or Hik-Connect
• iOS (iPhone): Free application iVMS-4500 or Hik-Connect
Default IP address: 192.168.1.64
Default admin user / password:
admin / -
The administrator password should be set at the first start
Web browser access ports: 80
PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application
Mobile client access ports: 8000
Port ONVIF: 80
RTSP URL:
• Main stream
rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ - with
authorization
• Sub stream
rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ - with
authorization
Power supply:
• PoE (802.3af),
• 12 V DC / 480 mA
Power consumption:
≤ 6.8 W @ PoE (802.3af)
≤ 5.8 W @ 12 V DC
Housing: Dome, Metal
Color: White
"Index of Protection": IP67
Vandal-proof:
Operation temp: -30 °C ... 60 °C

HIKVISION DS-2CD2386G2-I Specifications

General

Form factor	Turret
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Type	IP security camera
Certification	FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Languages support	Multi
Number of languages	33
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/1.8 \
Fixed focal length	2.8 mm
Detect distance (wide)	89.2 m
Maximum aperture number	1.6
Observe distance (wide)	35.4 m
Identify distance (wide)	8.9 m
Recognize distance (wide)	17.8 m
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Pan range	0 - 360 °
Tilt angle range	0 - 75 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	8 MP
Gain control type	Auto
Maximum resolution	3840 x 2160 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1200 (WUXGA), 2688 x 1520, 3200 x 1800, 3840 x 2160
Wi-Fi	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Security algorithms	TLS
Intelligent Video Surveillance (IVS) system features	Face detection, Scene change
Behavior analysis	Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
DC output current	0.48 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	5.8 W
Power consumption (Power over Ethernet (PoE))	6.8 W
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Signal-to-Noise Ratio (SNR)	52 dB

Weight and Dimensions

Length	126.3 mm
Weight	740 g
Diameter	138.3 mm
Package width	170 mm
Package height	150 mm
Package weight	1020 g
