User Manual of Network Fisheye Camera
27
Figure 4-8 Patrol Configuration (1)
2. Select a path No. from the drop-down list, and click the icon to configure
patrol path.
3. Click to add a preset into the path, and click to delete a preset.
4. Set the preset number, speed and lingering time at each preset. You can adjust the
order of presets by using and .
Figure 4-9 Patrol Configuration (2)
5. Click OK to save patrol path.
Note: Up to 32 patrol paths can be set, and each path supporting 16 key points at
most.
Calling a Patrol
Steps:
1. Click to select a PTZ View on the display window.
2. Select the patrol path number from the drop-down list.
3. Click the icon to start the selected patrol and to stop it.
Deleting a Patrol
1. Select the patrol path number from the drop-down list.
2. Click the icon to delete the patrol path.
