HIKVISION ds-2cd8153f-e Technical Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
4
Video
Compression
H.264/MPEG4/MJPEG
Video Bit Rate
32 Kbps – 16 Mbps
Audio
Compression
G.711/G.726
Audio Bit Rate
64Kbps(G.711) / 16Kbps(G.726)
Dual Stream
Yes
Max. Resolution
1600 x 1200
Frame Rate
50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25
fps (1280 × 720)
60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps
(1280 × 720)
Image Setting
Saturation, Brightness, Contrast adjustable by client software or web
browser
Network
Network Storage
NAS (iSCSI optional)
Alarm Trigger
Motion detection, Tampering alarm, Storage exception
Protocols
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,UPnP,
ICMP,IGMP,SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )
Security
User Authentication, Watermark
Standard
ONVIF, PSIA, CGI
Interface
Audio
Internal Microphone and Speaker
Communication
Interface
1 RJ45 10M/100M Ethernet port
On-board storage
Built-in Micro SD slot, up to 32 GB
Reset Button
Yes
Wi-Fi Specification(Only for the products with Wi-Fi module built-in)
Wireless Standards
IEEE802.11b, 802.11g, 802.11n Draft
Frequency Range
2.4 GHz ~ 2.4835 GHz
Channel
Bandwidth
20/40MHz Support
Protocols
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Output
Power
11b: 17±1.5dBm @ 11Mbps
11g: 14±1.5dBm @ 54Mbps
11n: 12.5±1.5dBm
Receive Sensitivity
11b: -90dBm @ 11Mbps (Typical)
11g: -75dBm @ 54Mpbs (Typical)
