1 Introduction
1.1 Product Features
The main features are as follows:
 High performance CMOS sensor
 IR cut filter with auto switch
 OSD menu with configurable parameters
 Auto white balance
 internal synchronization
 SMART IR mode
 Visible alarm
 PIR detection
 3-axis adjustment
1.2 Overview
This manual applies to two types of the bullet camera.
The overviews of each type are shown in the figures
below.
1.2.1 Overview of Type I Camera
Video Cable
(TVI)
Power Cord
Lens
Bracket
Main Body
PIR
White Light
Source
Figure 1-1 Overview of Type I Camera
1.2.2 Overview of Type II Camera
PIR
Main Body
Bracket
Video Cable
(TVI)
Power Cord
12 VDC
Lens
White Light Source
Figure 1-2 Overview of Type II Camera Installation
