©2006 – 2011 by HIKVISION. All rights reserved.
6
Client
GUI
Camera Control
Pan / Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call and program, Auto mode.
Camera Name
Up to 18 characters
Date & Time
Display
Time: Week: Date, 6 formats on the Client
Reading Patrol
Message
Display and reading of preset message contained in each patrol via client software
Fiber
Interface
(available
for fiber
dome
only)
Data Mode
10Base-T / 100Base-TX
Physical
Interface
FC(SC optional)
Fiber
Wavelength
TX1310/RX1550nm
Fiber Type
Single Fiber/Singlemode
Transmission
Distance
20Km, with 40Km, 60Km and 80Km optional
General
Menu Language
English, Chinese
RS-485
Protocols
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply
24VAC (12V DC optional)
(Hi-PoE optional, support 802.3at)
Power
Consumption
15W max(30W max with heater, outdoor dome)
Working
Temperature /
Humidity
-30 ℃-65℃(-22℉-149℉)(outdoor dome) / -10℃-50℃(14℉-122℉)(indoor dome )
90% or less
Protection
Level
IP66 standard (outdoor dome)
TVS 3,000V lightning protection, surge protection and voltage transient protection
Mounting
Various mounting modes optional
Dimension
Φ220×299.2mm (Φ8.66”×11.78”)(Outdoor)
Φ183.4×247mm(Φ7.22”×9.72”) (Indoor)
Φ245×240mm(Φ9.65”×9.45”) (In-ceiling)
Weight
(approx.)
5Kg (11.02Ibs)
Mount Option
long-arm wall mount: DS-1614ZJ; Indoor short-arm wall mount: DS-1615ZJ
Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ
