Figure 7-2 Calibration Area Lines
4.
Optional: Check Manual Correction and adjust the height range manually.
Note
Manual correction requires enough self-learning calibration time or targets.
1)Select Fig N (1~4).
2)You can click Previous or Next to change the target of each gure.
3)Input the actual height of the target. Click Save.
Calibrate Automatically
Before You Start
●
Make sure that you have known the actual height of the target person in the scene.
●
Make sure there is no moving objects in the view except for the person.
Steps
1.
Go to Conguration > Perimeter Protection > Camera Calibration or Conguration >
Perimeter Protection > Advanced
Conguration .
Note
The path varies according to different camera models.
2.
Check Camera Calibration.
3.
When the person is totally seen in live view, enter the height of person in Target Height.
Thermal & Optical Bi-spectrum Network Camera User Manual
71
