HIKVISION DS-2TD4166-25/V2

Thermal Network Speed Dome Quick Start Guide
9
3.3 Installing Memory Card
Steps:
1. Remove the protective sticker as shown in Figure 3-4.
Protective Sticker
Figure 3-4 Remove Protective Sticker
2. Remove the cover on the back of the speed dome. Insert the SD card to the SD card
slot and install the cover back.
SD Card Slot
Figure 3-5 SD Card Slot
3.4 Installing Speed Dome
1. Install the bracket.
1). Take out the bracket and all accessories.
