HIKVISION DS-2XE6222F-IS

Network Bullet Camera·Quick Start Guide
18
18
Pedestal
Mounting
Base
Screws
Safety
Rope
Figure 3-3 Fix the Camera to the Pedestal
4. Loosen the fixing screw, and adjust the panning position. Tighten
the fixing screw after adjustment.
Fixing Screw
Pan:
-45° to 45°
Figure 3-4 Adjust Panning Position
5. Use safety rope to hook the camera and the bracket. Adjust the
tilting position when screwing the camera to the wall mounting
bracket.
