Quick Operation Guide of DS-6700 Series Audio/Video Encoder
10
DS-6700HWI:
Model
DS-6701HWI
DS-6704HWI
DS-6708HWI
DS-6716HWI
Video/
Audio
input
Video
Compression
H.264/MPEG4/MPEG2/MJPEG
Video input
1-ch
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω)
Audio
Compression
G.711u
Audio Input
1-ch
4-ch
8-ch
16-ch
1-ch, 3.5mm interface
(2.0 Vp-p, 1 kΩ)
(LINE IN)
Line input interface (2.0 Vp-p, 1 kΩ)
Two-way audio
input
1-ch, 3.5mm interface
(2.0 Vp-p, 1 kΩ)
(LINE IN)
1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ)
Video/
Audio
output
Audio
output
1-ch, 3.5mm interface (Linear, 600 Ω)
Recording
resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
(WD1: 960×576/PAL, 960×480/NTSC)
Frame rate
H.264/MPEG4/MPEG2 encoding: 25 fps (P) / 30 fps (N); MJPEG encoding: 15 fps
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 8192 Mbps)
Audio bit rate
64 Kbps
Dual Stream
Support
Stream Type
Video / Video & Audio
Data
storage
Type
NAS, iSCSI, IPSAN, microSD
NAS, iSCSI, IPSAN
Capacity
Up to 4 TB capacity for each disk, and 32G for microSD storage
External
interface
Network
interface
1 RJ-45 10 M / 100 Mbps adaptive Ethernet
interface (PoE)
1 RJ-45 10 M / 100 M /1000 Mbps adaptive
Ethernet interface
Protocols and
Service
IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP, Bonjour, UPnP
TM
, Multicast,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, HiDDNS, NTP, RTSP, RTP/RTCP,TCP, UDP,
IGMP, ICMP, DHCP, ARP, SOCKSv4/v5, PSIA, ONVIF, CGI, IEEE802.1X, netFilter
Serial
interface
1 half-duplex RS-485
interface
1 half-duplex RS-485 interface; 1 RS-232 interface
Alarm in
1
4
8
16
Alarm out
1
2
4
4
General
Power supply
12 VDC
Power
Consumption
≤ 6W
≤ 8W
≤ 10W
≤ 22W
Working
temperature
-10°C ~ +55°C
Working
humidity
10% ~ 90%
Dimensions
(W × D × H)
80 × 90 × 39mm
114 × 128 × 48mm
315 × 200 × 45mm
440 × 274 × 45mm
Weight
≤ 0.5 Kg
≤ 1 Kg
≤ 2 Kg
≤ 4 Kg
