Quick Operation Guide of DS-6700 Series Audio/Video Encoder
4
DS-6708HWI/HFI and DS-6708HWI/HFI-SATA:
1
2
3
Description of front panel:
Indicator
Description
1
POWER
Lights in red when the device is powered on.
2
STATUS
Lights in red when data is being read from or written to HDD.
Valid for DS-6708HWI/HFI-SATA model only.
3
Tx/Rx
1. Does not light when the network is not connected;
2. Blinks in green when the data is transmitting / receiving;
3. Blinks at higher frequency when the data for transmitting / receiving is
larger.
DS-6716HWI/HFI and DS-6716HWI/HFI -SATA:
1 2 3
Description of front panel:
Indicator
Description
1
POWER
Lights in red when the device is powered on.
2
STATUS
Lights in red when data is being read from or written to HDD.
Valid for DS-6716HWI/HFI-SATA model only.
3
Tx/Rx
1. Does not light when the network is not connected;
2. Blinks in green when the data is transmitting / receiving;
3. Blinks at higher frequency when the data for transmitting / receiving is
larger.
