REAR PANELS (continued)
No.
Item
Description
1
VIDEO
IN
BNC connector for video
input
.
/P Models Only: Power-over-Coax (PoC) function provides power to PoC enabled cameras. Up to
984 ft (300 m) range when using AF RG6.
2
ALARM IN
Connectors for alarm inputs
3
AUDIO OUT
RCA connectors for audio output
4
VGA
DB
-
15 connector for VGA output
to display local video output and men
5
HDMI
HDMI video output connector
6
USB Interface
Connect to USB mouse or USB flash memory devices
7
LAN
Connector for LAN (Local Area Network)
8 RS-485
Connector for RS
-
485 devices: T+ and T
-
pins connect to R+
and R
-
pins of PTZ receiver
respectively
D+, D
-
pin connects to Ta, Tb pin of controller (for cascading devices, the first DVR’s D+, D
-
pin
should be connected with the D+, D
-
pin of the next DVR)
9
Power Input
P
ower
supply
connect
ion
10
Power Switch
Switch for turning device on/off
11
Ground
Connect before powering up
12
Video
Out
BNC connector for
CVBS
signal
out
13
Alarm I/O
Alarm input and output connectors
14
Alarm I/O Legend
Alarm input and output labels
1 CONNECT DEVICES
1. Connect power supply to the DVR.
2. Connect DVR to LAN using Cat 5e cable.
3. Connect video monitor(s) to DVR using HDMI and/or VGA cables, as appropriate.
4. Connect mouse to USB port (wireless mouse can be used in lieu of included mouse).
5. Connect to audio I/O using RCA connectors.
2 START THE DVR
1. Plug power supply plug into 110 to 240 VAC outlet (surge suppressor is recommended).
2. Turn power switch on. Power indicator LED will turn on to indicate unit is starting.
3. After startup, power indicator LED will remain on.
3 LOCAL ACTIVATION
System access requires a secure, user-assigned password.

HIKVISION DS-7204HUHI-K1 Specifications

General

Video Input	4 channels
Video Output	1 HDMI, 1 VGA
Video Bitrate	32 Kbps to 6 Mbps
Audio Bitrate	64 Kbps
Dual Stream	Yes
Stream Type	Video, Video & Audio
Synchronous Playback	4-ch
SATA	1 SATA interface
HDD Capacity	Up to 10 TB capacity for each disk
Network Interface	1, RJ45 10M/100M self-adaptive Ethernet interface
Power Supply	12 VDC
Operating Humidity	10% to 90%
Max Resolution	1080p
Video Compression	H.264+
Audio Output	1-ch RCA (Linear, 1 KΩ)
Two-Way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ)
HDMI Output	1
VGA Output	1
Recording Resolution	1080p
Playback Resolution	1080p
Network Protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS
USB Interface	2 USB 2.0
Operating Temperature	-10 °C to +55 °C
