Network Video Recorder User Manual
22
Table 1-2 Front Panel Description
Turns green when DVR is powered up.
Turns green, indicating that the DVR is functioning
properly.
Turns green when device is controlled by an IR
remote.
Turns red when controlled by a keyboard and purple
when IR remote and keyboard is used at the same
time.
Turns red when a sensor alarm is detected.
Flickers in red when data is being read from or written
to HDD.
Flickers in green when network connection is
functioning properly.
Switches between the numeric or letter input and
functions of the composite keys. (Input letter or
numbers when the light is out; Realize functions when
the light is red.)
Enters numeral “1”;
Accesses the main menu interface.
The F1 button when used in a list field will select all
items in the list;
Turns on/off PTZ light in PTZ Control mode, and use it
to zoom out the image;
To Next Page
