DS-73xxHUI-K4, DS-73xxHQI-K4, DS-90xxHUI-K8 DVR User Manual
UM DS-73xxHUI-K4 DS-73xxHQI-K4 DS-90xxHUI-K8 092017NA 34
Figure 34, IP Camera Management Interface
2. Online cameras with the same network segment will be detected and
displayed in the camera list.
3. Select the IP camera from the list and click to add the camera
(with the same admin password of the DVR). Or you can click
One-touch Adding to add all cameras (with the same admin password)
from the list.
Make sure the camera to add has already been activated by setting the
admin password, and the admin password of the camera is the same as
the DVR’s.
4. (Optional) Check the Enable H.265 checkbox (for Initial Access) for
the connected IP camera supporting H.265. Then the IP camera will
be encoded with H.265.
5. (For encoders with multiple channels only) check the Channel Port
checkbox in the pop-up window, as shown in the following figure, and
click OK to add multiple channels.
