Table 18 Specifications for DS-7300HWI-SH
Video input 4-ch 8-ch 16-ch 24-ch 32-ch
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio input 4-ch, RCA (2.0 Vp-p, 1 kΩ)
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 2-ch, RCA (Linear, 600 Ω)
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Channel 1-4: Video, Video & Audio;
SATA 4 SATA interfaces for 2HDDs + 1 DVD-R/W (default), or 4 HDDs
Capacity Up to 4TB capacity for each disk
Network interface 1, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface 1 RS-232, RS-485(half-duplex), Keyboard
1RS-232,RS-485(full-duplex)
USB interface 3 × USB 2.0
Power supply 100~240VAC, 5A, 50~60Hz
≤ 25 W ≤ 30 W ≤ 35 W ≤ 40 W
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 1.5U chassis
