HIKVISION DS-7308HFI-SH User Manual

Quick Operation Guide of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR
26
Table 22 Specifications for DS-8124/8132HWSI-SH
Model
DS-8124HWSI-SH DS-8132HWSI-SH
Video/Audio input
Video compression H.264
Video input 24-ch 32-ch
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive
Audio compression G.711u
Audio input
16-ch,
Audio 1-4: RCA (2.0 Vp-p, 1 kΩ); Audio 5-16: DB26 connector
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 2-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbps
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Channel 1-16: Video, Video & Audio;
Other channels: Video
Synchronous playback 16-ch
Hard disk
SATA 8 SATA interfaces for 4HDDs + 1 DVD-R/W (default), or 8 HDDs
eSATA 1 eSATA interface
Capacity Up to 4TB capacity
External interface
Network interface 2, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface 1 RS-232, RS-485(full-duplex), Keyboard
USB interface 3 × USB 2.0
Alarm in 16
Alarm out 8
General
Power supply 100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 40 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 95 mm
Weight
(without HDD or
DVD-R/W)
≤ 8 kg

HIKVISION DS-7308HFI-SH Specifications

General

Brand	HIKVISION
Model	DS-7308HFI-SH
Category	DVR
Language	English
