Digital Video Recorder User Manual
149
Figure 10-8 Set Intrusion Crossing Detection Rules
4) Click OK to save the rule settings and back to the line crossing detection settings interface.
Step 7 Click and draw a quadrilateral in the preview window by specifying four vertexes of
the detection region, and right click to complete drawing. Only one region can be
configured.
You can use the to clear the existing virtual line and re-draw it.
Up to 4 rules can be configured.
Figure 10-9 Draw Area for Intrusion Detection
Step 8 Click Apply to save the settings.
The sudden scene change detection and the intrusion detection cannot be enabled at the same
channel.
10.5 Region Entrance Detection
Purpose
