HIKVISION DS-7600NI-E1/E2 series Quick Start Guide




R E A R P A N E L S
Figure 2, DS-7604NI-E1/4P Rear Panel
Figure 3, DS-7608NI-E2/8P Rear Panel
Figure 4, DS-7616NI-E2/16P
No.
Item
Description
1
Audio In
RCA
connector
2
Audio Out
RCA
connector
3
VGA
Out
DB
-
15 connector for VGA output
to d
isplay local video output and
menu
4
HDMI Out
HDMI video output
connector
5
Alarm I/O
A
larm
input
/
output
connectors
6
LAN Interface
Connector for LAN (Local Area Network)
7
USB
USB
port for additional
devices
8
Grounding Screw
Ground (needs to be connected when NVR starts up)
9
Power Input
48 VDC power supply (DS
-
7604
NI
-
E1/4P
)/
100 to 240 VAC
(DS
-
7608NI
-
E2/8P, DS
-
7616NI
-
E2/16P)
10
Power Switch
Switch for turning on/off the
device
11
Network Interfaces w/PoE
IP camera input
s
and PoE output
s
