HIKVISION DS-7608NI-E2/8P Quick Start Guide

www.hikvision.com/en/us
After the changes have been made, presses “APPLY”. A “SUCCESS” message will pop up
If the Domain Name does not meet the acceptable criteria, and/or is already registered, an error message
will appear(The domain name cannot contain upper case characters, begin with a number, spaces,
special characters…).
SETTING UP NETWORK ACCESS
Enable DDNS and
create a DOMAIN
NAME
EZVIZ is used for a
connection through a
secure server.
In this case port
forwarding is not
required.
Please contact
Technical Support
for detailed
information

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
