Specifications of DS-7600NI-ST
Model
DS-7608NI-ST
DS-7616NI-ST
Video/Audio
input
IP video input
8-ch
16-ch
Audio in
1-ch, BNC (2.0 Vp-p, 1kΩ) (Two-way audio)
Video/Audio
output
Recording
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
HDMI output
1-ch, resolution:
1920 × 1080P /60Hz, 1920 × 1080P /50Hz, 1600 × 1200 /60Hz, 1280
× 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280
× 720 /60Hz, 1024 × 768 /60Hz
Audio output
1-ch, BNC (Linear, 600Ω)
Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
Synchronous
playback
8-ch
16-ch
Hard disk
SATA
2 SATA interfaces
Capacity
Each interface supports up to 4TB capacity for recording
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
Serial interface
1 RS-232 interface (for parameters configuration, maintenance,
transparent channel);
1 RS-485 interface (reserved);
USB interface
2 × USB 2.0
Alarm in
4
Alarm out
2
Others
Power supply
12 VDC
Consumption
≤ 13 W (without hard disk or DVD-R/W)
Working
temperature
-10 ℃ ~ +55 ℃
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
445 × 261 ×44.5 mm
Weight
≤ 4 Kg (8.82 lb) ( without hard disk or DVD-R/W )
