HIKVISION DS-9608NI-ST

Quick Operation Guide of Network Video Recorder
20
Specifications of DS-9600NI-RT
Model
DS-9608NI-R
T
DS-9616NI-R
T
DS-9632NI-R
T
DS-9664NI-R
T
Video/Audio
input
IP video input
8-ch
16-ch
32-ch
64-ch
Two-way audio
1-ch, BNC (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
40Mbps
80Mbps
160Mbps
160Mbps
Outgoing bandwidth
240Mbps
240Mbps
160Mbps
160Mbps
Remote Connection
128
Video/Audio
output
Recording resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
HDMI output
1-ch, resolution:
1920 × 1080P /60Hz, 1920×1080P /50Hz, 1600 × 1200/60Hz, 1280
× 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,
1280 × 720 /60Hz, 1024 × 768 /60Hz
Audio output
2-ch, BNC (Linear, 600Ω)
Decoding
Live view / Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
Capability
8-ch@720P,
4-ch@1080P
16-ch@720P,
8-ch@1080P
16-ch@720P,
8-ch@1080P
16-ch@720P,
8-ch@1080P
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each HDD
Disk array
Array type
RAID0, RAID1, RAID5, RAID10
Number of array
4
Number of virtual
disk
8
External
interface
Network interface
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial interface
RS-232; RS-485; Keyboard;
USB interface
3 × USB 2.0
Alarm in/out
16/4
Others
Power supply
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz
Consumption
(without hard disk
or DVD-R/W)
≤ 35 W
≤ 40 W
≤ 45 W
≤ 45 W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 ×90 mm (17.5" ×18.5"× 3.5")
Weight
(without hard disk
or DVD-R/W)
≤ 8 Kg (17.64 lb)
