HIKVISION DS-K2602 User Manual

DS-K2600 Serial Access Controller
16
No.
DS-K2604
A23
Weigand
Card Reader
1
GND
Grounding
A24
W0
Weigand Card Reader Data Input Data0
A25
W1
Weigand Card Reader Data Input Data1
A26
BZ
Buzzer of Card Reader Control Output
A27
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A28
OK
Cresset of Card Reader Control Output (Valid
Card Output)
B1
Arming
Region
Input
Z1
Arming Region Access Terminal 1 (Only for
Linkage of Alarm Relay Output)
B2
GND
Grounding
B3
Z2
Arming Region Access Terminal 2 (Only for
Linkage of Alarm Relay Output)
B4
Z3
Arming Region Access Terminal 3 (Only for
Linkage of Alarm Relay Output)
B5
GND
Grounding
B6
Z4
Arming Region Access Terminal 4 (Only for
Linkage of Alarm Relay Output)
B7
E-Lock 1
D1+
Door 1 Door Relay Input (Dry Contact)
B8
D1-
B9
E-Lock 2
D2+
Door 2 Door Relay Input (Dry Contact)
B10
D2-
B11
E-Lock 3
D3+
Door 3 Door Relay Input (Dry Contact)
B12
D3-
B13
E-Lock 4
D4+
Door 4 Door Relay Input (Dry Contact)
B14
D4-
B15
Door
S1
Door 1 Magnetic Detector Input

HIKVISION DS-K2602 Specifications

General

Product type	Access controller
Certification	CE, FCC
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	370 mm
Width	345 mm
Height	90 mm
