HIKVISION DS-K2604

DS-K2600 Series Access Controller
9
No.
DS-K2601
B3
Z2
Arming Region Access Terminal 2 (Only for
Linkage of Alarm Relay Output)
B4
Z3
Arming Region Access Terminal 3 (Only for
Linkage of Alarm Relay Output)
B5
GND
Grounding
B6
Z4
Arming Region Access Terminal 4 (Only for
Linkage of Alarm Relay Output)
B7
E-Lock
D1+
Door 1 Door Relay Input (Dry Contact)
B8
D1-
B9
Door
Contact
Input
S1
Door 1 Door Contact Detector Input
B10
GND
Grounding
B11
Door Open
Button
B1
Door 1 Door Open Button Input
B12
GND
Grounding
C1
Power
+12V
DC12V Cathode
C2
GND
DC12V Grounding Input
C3
Battery
BAT+
DC12V Battery Cathode
C4
BAT-
DC12V Battery Anode
C5
485 Card
Reader
RS
485A+
Card Reader RS485+ Access
C6
RS 485A-
Card Reader RS485- Access
C7
GND
Grounding
C8
RS
485B+
Card Reader RS485+
C9
RS 485B-
Card Reader RS485-
