HIKVISION DS-K2604

DS-K2600 Series Access Controller
13
No.
DS-K2602
A19
2
W1
Wiegand Head Read Data Input Data1
A20
BZ
Card Reader Buzzer Control Output
A21
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A22
OK
Indicator of Card Reader Control Output (Valid
Card Output)
A23
Wiegand
Card Reader
1
GND
Grounding
A24
W0
Wiegand Head Read Data Input Data0
A25
W1
Wiegand Head Read Data Input Data1
A26
BZ
Card Reader Buzzer Control Output
A27
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A28
OK
Indicator of Card Reader Control Output (Valid
Card Output)
B1
Arming
Region
Z1
Arming Region Access Terminal 1 (Only for
Linkage of Alarm Relay Output)
B2
GND
Grounding
B3
Z2
Arming Region Access Terminal 2 (Only for
Linkage of Alarm Relay Output)
B4
Z3
Arming Region Access Terminal 3 (Only for
Linkage of Alarm Relay Output)
B5
GND
Grounding
B6
Z4
Arming Region Access Terminal 4 (Only for
Linkage of Alarm Relay Output)
B7
E-Lock1
D1+
Door 1 Door Relay Input (Dry Contact)
