HIKVISION DS-K2604 Quick Start Guides

DS-K2600 Series Access Controller
17
No.
DS-K2604
A5
Wiegand
Card Reader
4
GND
Grounding
A6
W0
Wiegand Card Reader Data Input Data0
A7
W1
Wiegand Card Reader Data Input Data1
A8
BZ
Buzzer of Card Reader Control Output
A9
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A10
OK
Cresset of Card Reader Control Output (Valid
Card Output)
A11
Wiegand
Card Reader
3
GND
Grounding
A12
W0
Wiegand Card Reader Data Input Data0
A13
W1
Wiegand Card Reader Data Input Data1
A14
BZ
Buzzer of Card Reader Control Output
A15
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A16
OK
Cresset of Card Reader Control Output (Valid
Card Output)
A17
Wiegand
Card Reader
2
GND
Grounding
A18
W0
Wiegand Card Reader Data Input Data0
A19
W1
Wiegand Card Reader Data Input Data1
A20
BZ
Buzzer of Card Reader Control Output
A21
ERR
Cresset of Card Reader Control Output
(Invalid Card Output)
A22
OK
Cresset of Card Reader Control Output (Valid
Card Output)

HIKVISION DS-K2604 Specifications

General

Product type	Access controller
Certification	CE, FCC
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	370 mm
Width	345 mm
Height	90 mm
