HIKVISION DS-K2802 User Manual

Access Control Terminal·User Manual
6
No.
DS-K2802
E3
Alarm Output 1
COM1
Alarm Relay Output 1 (Dry Contact)
E4
NO/NC1
C1
Wiegand Card
Reader 1
OK
Indicator of Card Reader Control Output (Valid Card
Output)
C2
ERR
Indicator of Card Reader Control Output (Invalid Card
Output)
C3
BZ
Card Reader Buzzer Control Output
C4
W1
Wiegand Head Read Data Input Data1
C5
W0
Wiegand Head Read Data Input Data0
C6
PWR
Card Reader Power Output
C7
GND
C8
Wiegand Card
Reader 2
OK
Indicator of Card Reader Control Output (Valid Card
Output)
C9
ERR
Indicator of Card Reader Control Output (Invalid Card
Output)
C10
BZ
Card Reader Buzzer Control Output
C11
W1
Wiegand Head Read Data Input Data1
C12
W0
Wiegand Head Read Data Input Data0
C13
PWR
Card Reader Power Output
C14
GND
C15
Wiegand Card
Reader 3
OK
Indicator of Card Reader Control Output (Valid Card
Output)
C16
ERR
Indicator of Card Reader Control Output (Invalid Card
Output)
C17
BZ
Card Reader Buzzer Control Output
C18
W1
Wiegand Head Read Data Input Data1
C19
W0
Wiegand Head Read Data Input Data0
C20
PWR
Card Reader Power Output
C21
GND
C22
Wiegand Card
Reader 4
OK
Indicator of Card Reader Control Output (Valid Card
Output)
C23
ERR
Indicator of Card Reader Control Output (Invalid Card
Output)
C24
BZ
Card Reader Buzzer Control Output
C25
W1
Wiegand Head Read Data Input Data1
C26
W0
Wiegand Head Read Data Input Data0
C27
PWR
Card Reader Power Output
C28
GND

HIKVISION DS-K2802 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
