HIKVISION DS-K2804 Quick Start Guide

DS-K2800 Serial Access Controller
13
No.
DS-K2804
B4
W1
Wiegand Head Read Data Input Data1
B5
W0
Wiegand Head Read Data Input Data0
B6
PWR
Card Reader Power Output
B7
GND
B8
Wiegand Card Reader 2
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B9
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B10
BZ
Card Reader Buzzer Control Output
B11
W1
Wiegand Head Read Data Input Data1
B12
W0
Wiegand Head Read Data Input Data0
B13
PWR
Card Reader Power Output
B14
GND
B15
Wiegand Card Reader 3
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B16
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B17
BZ
Card Reader Buzzer Control Output
B18
W1
Wiegand Head Read Data Input Data1
B19
W0
Wiegand Head Read Data Input Data0
B20
PWR
Card Reader Power Output
B21
GND
B22
Wiegand Card Reader 4
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B23
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B24
BZ
Card Reader Buzzer Control Output
B25
W1
Wiegand Head Read Data Input Data1
B26
W0
Wiegand Head Read Data Input Data0

HIKVISION DS-K2804 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
