User Manual
Code: DS-KIS701-W-D
VIDEO DOORPHONE KIT DS-KIS701-W-D Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-08-20 DS-KIS701-W-D 2/11
Sensor: 2.1 Mpx CMOS
Image compression method: H.264
LED illuminator:
IR illuminator:
Compatibility: HIKVISION 2-wire Video Doorphones
Main features:
• Doorbell button,
• Bidirectional communication,
• Microphone built-in,
• Speakers built-in,
• Tamper detection - removing from mounting surface,
• LEDs for system state indication and user interface display,
• Door contact and request button for exit inputs,
• The device has the ability to work with the Hik-Connect application for mobile
devices,
• Relay output : NO/NC
Operation temp: -30 °C ... 60 °C
Power supply: 24 V DC - via DS-KAD709
Housing: Metal, Waterproof
Color: Silver
"Index of Protection": IP65
Weight: 0.79
Dimensions: 169 x 110 x 52
INDOOR PANEL:
Shield: 7 " capacitive touch screen
Resolution: 1024 x 600
Internal memory:
Memory card slot: SD memory cards up to 32GB support (possible local recording)
Mobile phones support:
• Android: Free application Hik-Connect
• iOS (iPhone): Free application Hik-Connect
Default administrator password: 888999
Main features:
• Microphone built-in,
• Speakers built-in,
• Bidirectional communication,
• Smooth adjustment of monitor parameters: image brightness, ring tone volume and
conversation volume,
• Automatically capture and save images if there is no response to the doorbell,
• Support for capturing a photo during video calls,
• Register a short voice message if there is no response to the bell button,
• Full support via network,
• LEDs for system state indication and user interface display,
• Possibility to connect up to 3 compatible devices (door stations, internal panels,
KAD-709 controller),
• IP Hikvision cameras support
Controlling: One-touch action buttons + capacitive touch screen
Alarm inputs:
