Configure the address via DIP switch of the keypad before powering on the
system. The address should be in the range (for Network Control Panel, 0 to 31;
for Hybrid Control Panel, 0 to 23). The address of each keypad should be unique.
The binary value shown in the diagram is 00010, which means the decimal value
is 2. So the address of the keypad is 2.
Three Beeps: Keypad enrolled.
a. Dimension
b. Wiring
Note: Hybrid control panel does not support Z1, GND, NO/NC, COM.
c. Install Keypad
(1) Gangbox Moung
(2) Wall Moung
It is required to insert the screw for tamper alarm.
Indicator
Key
Beeps
Wiring and Installaon
English
Diagram Reference
Product Information
Specification
Components and Beeps
1
3
Operaon Commands4
Address Sengs
2
1 2
3
Alarm Keypad
164.13 mm
30.96 mm
124.11 mm
a
b
c
Query
Set
Fault
Network
Armed/Disarmed
Alarm
Fire Panic
One-Push to Arm
Project Bypass Scoll Up
Scoll Down
Solid Green: No Configuraon
Flashing Green: In the Configuraon Status
Solid Green: All Enabled Channels Connected Normally
Flashing Red: Alarm Occurred/Tamper Alarm
Solid Blue: Armed
Off: Disarmed
Off: No Alarm
Off: Part of or All Enabled Channels Connected Abnormally
Solid Orange: System Fault
Off: No Fault
D- D+ 12V
GND
D- D+ 12V
GND
Control Panel
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the RE Direcve 2014/53/EU,
the EMC Direcve 2014/30/EU, the LVD Direcve
2014/35/EU, the RoHS Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For
more informaon see: www.recyclethis.info
The Input voltage should meet both the SELV (Safety
Extra Low Voltage) and the Limited Power Source
according to the IEC60950-1 standard. Please refer
to technical specificaons for detailed informaon.
BIN=00010
DEC=2
E.G
1 2 3 4 5
(1) GANGBOX MOUNTING
(2) WALL MOUNTING
Hybrid control panel does not support Z1, GND,
NO/NC, COM.
Scan the QR code a to get operaon commands of Hybrid control panel.
HighbitLowbit
UD15865B-D
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All
rights reserved.
About this Manual
The Manual includes instrucons for using and managing
the Product. Pictures, charts, images and all other
informaon hereinaer are for descripon and explanaon
only. The informaon contained in the Manual is subject to
change, without noce, due to firmware updates or other
reasons. Please find the latest version of this Manual at the
Hikvision website (hps://www.hikvision.com/).
Please use this Manual with the guidance and assistance of
professionals trained in supporng the Product.
Trademarks
and other Hikvision's trademarks and logos
are the properes of Hikvision in various jurisdicons. Other
trademarks and logos menoned are the properes of their
respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS
MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A
PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT
YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU
FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA,
CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN
CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET
PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM
CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER
INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN
A MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD
PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY,
INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR
ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR
PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE
DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL
WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND
THE APPLICABLE LAW, THE LATER PREVAILS.
4
Legal and Regulatory Information
1. The addional force shall be equal to three mes the
weight of the equipment but not less than 50N. The
equipment and its associated mounng means shall remain
secure during the installaon. Aer the installaon, the
equipment, including any associated mounng plate, shall not
be damaged.
2. Install the equipment according to the instrucons in this
manual.
3. To prevent injury, this equipment must be securely
aached to the wall in accordance with the installaon
instrucons.
INSTALLATION CAUTION
Medicine
One Beep: Pressing keys/command med out or too long.
Two Beeps: Valid command/Report uploaded.
Five Beeps: Invalid command/Failed to upload the report in 60s.
Connuous Beeping For Two Seconds: Fault prompt (Only for the Network
Control Panel)
Slowly Connuous Beeps: In the Entry/Exit delay status.
Rapidly Connuous Beeps: In the Entry/Exit delay status, 10 seconds countdown.
Rapid Beeps: Zone alarm/keypad not enrolled.
Three Long Beeps and Two Short Beeps: Keypad tampered.
Model DS-PK-L DS-PK-LR DS-PK-LRT DS-PK-LRTE
Numeric key
Funcon key
Display
Keyfob N/A N/A Two-way keyfob Two-way keyfob
Tamper switch
RS-485 interface
Sound
Tag/Card reading N/A N/A Support Support
Power supply
Power
consumpon
Temperature
Humidity
Dimension
(L × W × H)
Weight
164 mm × 124 mm × 31 mm
272 g
1
1
buzzer
12 V, 0.15 A
1.8 W
12 keys: 0 to 9, *, #
8 keys: Project/Query/Bypass/One-push to arm/Fire/Panic/Scroll
up/Scroll down
LCD screen
10% to 90%
-10 °C to 55 °C
