The number of captured picture(s).
Capture Interval
The me between the adjacent captures.
4.
Set connuous capture parameters. Refer to Set Connuous Capture Parameters for details.
5.
Set the lane parameters. Refer to Set Linked Lane Parameters for details.
6.
Oponal: Check the other lane(s) to copy the same sengs.
7.
Draw lane lines.
1) Click Draw Lane Line.
Note
The system will capture a picture and use it as the background. You can also check Video
Background to use the live view as the background.
2) Select the default lane lines, trigger line, and right border line, and drag the two end points of
the line or drag the whole line to adjust its posion according to the actual scene.
3) Oponal: Click Redraw Lane Line to redraw the lines.
4) Click OK.
Network Trac Camera Conguraon Manual
17
