HIKVISION iDS-TCE500-B Configuration Manual

Enable the funcon, and the target track will be displayed on the interface according to the
detected coordinates.
Advanced Sengs
Debug Mode
Enable the radar debugging mode. In this mode, the vehicles outside the drawn area will
be displayed, to make it convenient to debug the radar.
Sensivity
The lower the sensivity is, the more sensive the detecon will be. For the detecon
which is too sensive (e.g., some xed facilies, such as the bus staon on the lane, are
detected as vehicles), you can adjust the
sensivity higher.
Inuenal Range X
If you do not want to adjust the total sensivity, enter the vercal distance from the
possible mistakenly recognized area (such as the bus staon) to the camera.
Note
The inuenal range of the sensivity can be set every 50 m, and up to four areas can be
set.
Range X Sensivity
You can adjust the sensivity of each inuenal range independently.
Target Dwell Time
The dwell me of the vehicle. Set it as 0 when measuring the queue length.
Radar Predicon
Enable the funcon, and the radar will predict the target track which can be displayed on
the interface according to the detected coordinates.
Radar Port Mapping
Enable the
funcon and SSH Service, the debugging command with radar conguraon
informaon will be sent to the device.
Radar Detecon Distance
It is the range of the radar track. The default value is 200 m. You can select the value to
adjust the radar track range.
Distance to Stop Line
It is the distance from the point on the ground just below the installed radar to the stop
line at the
intersecon. The targets detected in this range will be ltered.
Wave Band ID
0 to 4 stand for ve frequencies. Set dierent wave bands for dierent radars in the same
scene to prevent the radars in the same wave band from
inuencing each other.
Heading Angle Calibraon
Network Trac Camera Conguraon Manual
65
