HIKVISION iDS-TCE907-BR Configuration Manual

Figure 1-1 Set Checkpoint Single I/O
3.
Oponal: Select the violaon type(s) to be detected, and set the corresponding parameters.
Refer to Set Violaon and Incident Detecon for details.
4.
Set scene and mode parameters. Refer to Set Scene Mode for details.
5.
Check the corresponding External Input according to the connected I/O signal.
Note
Each input corresponds to one lane.
6.
Oponal: Check Emergency Lane Occupaon Capture if you want to detect the violaon of
occupying emergency lane.
7.
Set the lane parameters. Refer to
Set Linked Lane Parameters for details.
8.
Set the parameters below.
I/O Trigger Mode
Network Trac Camera Conguraon Manual
2

HIKVISION iDS-TCE907-BR Specifications

General

Brand	HIKVISION
Model	iDS-TCE907-BR
Category	Security Camera
Language	English
