HIKVISION iDS-TCM403-A Configuration Manual

Figure 1-11 Set License Plate Recognion System
3.
Select Trigger Type.
Video
Detecon
The passing vehicles will be recognized via videos. The capture mode is recommended as
Strobe Light Mode.
I/O Coil
Select it when the device has been connected to I/O signal.
Note
The trigger types vary with dierent models. The actual device prevails.
4.
Select Picture Type.
Scene Picture
Only one passing vehicle picture will be output.
Scene Picture + Close-up Picture
One passing vehicle picture and one close-up picture will be output.
5.
Set the lane parameters. Refer to
Set Linked Lane Parameters for details.
6.
Set other parameters according to the selected trigger type.
I/O Trigger Default Status
Network Trac Camera Conguraon Manual
16
