HIKVISION Ultra Series Quick Start Guide

Network Box Camera·Quick Start Guide
24
Wall Mount
Horizontal Pole Mount
Pendant Mount
1). Install the bracket onto the wall/ceiling/pole. The wall
mounting bracket, pole mounting bracket, and the pendent
bracket are shown in the figures below.
Wall
Wall Mount
Pole
Pole
Mount
Figure 2-12 Install the Bracket to Mounting Place (1)
Ceiling
Pendant
Mount
Figure 2-13 Install the Bracket to Mounting Place (2)
2). Fix the housing (with camera) onto the bracket with the
supplied screws.
3). Loosen the adjusting screw to adjust the surveillance angle of
the camera. Tighten the screw after adjustment.
