Step 5
Place the BackSaver supplied large washer from
Step 1 over the bolt of the Hilti® forward handle
as shown in the photo; then screw the Hilti®
forward handle back on loosely.
*Do NOT tighten the handle until the end of Step
6
*Note, if attaching the TE-50 Hilti® hammer drill,
place the BackSaver supplied small washer over
the bolt of the Hilti® forward handle
