English 9
@
Connecting sleeve
;
Securing screws for scaffold hook
=
Scaffold hook
%
Speed control wheel
&
Grip
(
Battery charge-status and fault indicator
)
Battery release buttons (also used to
activate the charge status indicator)
+
Battery
§
LED to illuminate the working area
/
Switch
:
Piston-rod release button
∙
Cartridge holder
$
Short piston rod
£
Ergonomic grip
|
Securing screw for ergonomic grip
¡
Allen wrench for the scaffold hook and grip
Q
Front panel
W
Aluminum tube
E
Piston attachment for processing foil packs
R
Long piston rod
3.2 Items supplied
Dispenser, scaffold hook complete, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or online at:
www.hilti.group | USA: www.hilti.com.
3.3 Intended use
The product is intended for emptying Hilti foil packs and cartridges. The CD 4-A22 cordless dispenser is
designed exclusively for processing Hilti 300 ml or 600 ml foil packs and 300 ml or 310 ml cartridges.
The product can be operated with a cartridge holder or an aluminum tube:
▶ Use this product only with the Hilti cartridge holder set with included piston rod: Used to process Hilti
cartridges.
▶ Use this product only with the Hilti aluminum tube set with included piston rod: For processing Hilti foil
packs.
▶ Use only Hilti Li-ion batteries of the B22 series with this product.
▶ Use only Hilti battery chargers of the C4/36 series for these batteries.
3.4 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are indicated by the display on the Liion
battery. The Liion battery state of charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
Printed: 10.04.2019 | Doc-Nr: PUB / 5466601 / 000 / 01

Hilti CD 4-A22 Specifications

General

Battery Voltage	21.6 V
Battery Type	Li-ion
Type	Cordless Rivet Tool
Power Source	Battery
Weight	2.5 kg
