Location of identification data on the appliance
The type designation and serial number can be found
on the type identification plate on the appliance. Make
a note of this data in your operating instructions and
always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
Generation: 01
Serial no.:
2. Description
2.1 Use of the product as directed
The pump is intended for operation in conjunction
with vacuum fastening devices as used, for example,
with Hilti diamond coringmachines(uptoa maximum
coring diameter of 250 mm).
It is designed to be used as an air suction pump and
is not to be used for other gases and certainly not for
liquids.
It is equipped with a water separator in case of use
where the presence of water is essential (e.g. diamond
core drilling).
Operation in locations where there is a risk of explo-
sion (e.g. in the immediate vicinity of gas tanks) is
not permissible.
This appliance is not intended for use by persons
(including children) with physical, sensory or mental
disabilities or persons lacking the appropriate exper-
ience and/or knowledge.
Check the electrical specification given on the motor
rating plate. The appliance may be powered only by an
AC electric supply in compliance with the specification
given on the rating plate.
Observe the information printed in the operating in-
structions concerning operation, care and mainten-
ance.
The appliance is designed for professional use and
may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must
be informed of any special hazards that may be en-
countered. The appliance and its ancillary equipment
may present hazards when used incorrectly by un-
trained personnel or when used not as directed.
To avoid the risk of injury, use only genuine Hilti tools
and accessories.
2.2 Items supplied
1 The appliance
1 Operating instructions
3. Spare parts
Water separator 2
1 Water separator 412483
4. Technical data
Right of technical changes reserved.
Rated voltage 100 V 110 V 230 V 240 V
Rated current: see
motor rating plate
5.4 / 6.0 A 4.5 A 2.1 A 2.1 A
Power input 440 / 570 W 450 W 450 W 500 W
Frequency 50 / 60 Hz 50 Hz 50 Hz 50 Hz
Protection class I (earthed / groun-
ded)
I (earthed / groun-
ded)
I (earthed / groun-
ded)
I (earthed / groun-
ded)
